Swivel expansion joints, pipe swivel expansion joints, Pipes Swivel expansion joints, two for a group of two installations ,
Power plant piping is selected with rotating expansion joints
Metal pipes have a large expansion capacity expansion joint
Swivel Expansion Joint :
The sealing packing adopts the most advanced packing in China, with temperature resistance of -60 °C - 800 °C.
The swivel expansion joint, the outer casing of the inner casing and the inner casing of the outer casing are welded with retaining rings,
A rolling ring is installed between the two rings to reduce friction.
Reduces the wear of the inner sleeve on the sealing packing.
And because the natural tension of multiple sets of springs on the compensator device pushes the packing gland flange,
The seal packing, which is extremely lightly worn, is always compact,
So that the liquid or gaseous medium in the pipeline does not leak,
When the weariness of the filler is large, the spring tension cannot meet the adjustment.
The spring compression can be adjusted by external force to achieve the required sealing effect without stopping the working state.
